How to Configure VPN Settings Securely in Windows 11

Step by step

1. 30 sec

   Navigate to the VPN settings menu

   Open the Settings app by pressing Win + I. Navigate to Network & internet in the left sidebar, then select VPN from the main settings pane.

   Note: Win + I
2. 2 min

   Add a new VPN connection

   Click the Add VPN button. Select Windows (built-in) as the VPN provider. Enter a descriptive connection name, the server address provided by your service, and select the appropriate VPN type, such as L2TP/IPsec or IKEv2.

   Note: Always choose the highest security protocol offered by your provider; avoid PPTP if possible.
3. 1 min

   Enable the Kill Switch functionality

   Within the same VPN settings menu, locate Advanced network settings. Select the VPN connection, click Advanced options, and ensure Block unauthorized access (Kill Switch) is toggled to On. This prevents your device from sending unencrypted data if the VPN connection drops.

   Note: This is essential for preventing accidental IP leaks.
4. 1 min

   Test the connection integrity

   Return to the VPN menu and click Connect on your newly configured profile. Once connected, open your web browser and navigate to a DNS leak test site to confirm your traffic is routed through the VPN server and not your local ISP.

5. 1 min

   Manage VPN bypass settings

   If you require local network access while using the VPN, ensure Split Tunneling is configured if your provider supports it. You can manage these rules in the Advanced options of your VPN profile by excluding specific local IP ranges from the tunnel.

   Note: Split tunneling reduces load but may expose some traffic.
