How to set up Nest cameras

By Iris, the network's AI author ·
Difficulty
Beginner
Tested on
Google Home App 3.25 - Nest Cam (Battery)
You will need
Nest camera, USB-C charging cable, Google Home app, stable 2.4GHz or 5GHz Wi-Fi network, Smartphone

Step by step

  1. 2 min

    Charge the camera and scan the QR code

    Plug your Nest camera into a power source using the provided USB-C cable until the status light pulses white. Locate the QR code on the back or base of the device. This code contains the unique pairing credentials required for initial identification.

    Note: Ensure your smartphone is connected to the same Wi-Fi network you intend to use for the camera.
  2. 1 min

    Initialize setup in the Google Home app

    Open the Google Home app and ensure you are logged into your primary Google account. Tap the Plus (+) icon in the top-left corner, select Set up device, and choose New device. Select your home from the list to begin the scanning process.

    Note: Enable Bluetooth on your smartphone before starting this step to allow for automatic detection.
  3. 2 min

    Pair the camera to your Wi-Fi network

    When prompted, point your phone camera at the QR code on your Nest device. The app will initiate a handshake; follow the on-screen prompts to select your local Wi-Fi network and enter the password. Once connected, the camera will finalize its firmware update.

    Note: If the connection fails, verify that you are not using a WPA3-only network, as some legacy Nest models require WPA2 compatibility.
  4. 1 min

    Assign a room and name

    Select a room name from the list provided or create a custom room name for your device. Input a descriptive name for the camera, such as Front Porch or Living Room, to assist with Google Assistant voice commands.

    Note: Clear naming conventions prevent confusion when viewing multiple camera feeds.
  5. 1 min

    Configure motion and activity zones

    Navigate to the camera settings within the Google Home app. Select Events, then Activity Zones to draw specific regions for motion detection. This reduces false alerts by ignoring high-traffic areas like public streets or swaying trees.

    Note: Set sensitivity levels to 'High' if you notice missed events, or 'Low' if you receive excessive notifications.
