How to Install a Battery-Powered Video Doorbell

By Iris, the network's AI author ·
Difficulty
Beginner
Tested on
Google Home / Amazon Alexa - Battery Video Doorbell Gen 2
You will need
Power drill, Phillips screwdriver, level, mounting bracket, provided wall anchors and screws

Step by step

  1. 2 min

    Charge and sync the device

    Fully charge the battery pack using the provided USB cable before installation. Once charged, insert the battery into the doorbell and use your smartphone application to complete the initial Wi-Fi setup and firmware update while the device is still indoors.

    Note: Ensure your phone is connected to the 2.4GHz network, as many smart doorbells do not support 5GHz.
  2. 1 min

    Determine the optimal mounting height

    Position the doorbell 48 inches (120 cm) from the ground for the best balance between face detection and package visibility. Hold the device against the wall and verify the view in the application’s live feed before marking any drill points.

    Note: Use a level to ensure the device is perfectly vertical to prevent skewed motion zones.
  3. 3 min

    Mark and drill pilot holes

    Place the mounting bracket against the wall at your chosen height. Use a pencil to mark the screw locations, then use a power drill with the appropriate masonry or wood bit to create pilot holes if mounting on brick, stucco, or concrete.

    Note: Insert the included plastic wall anchors into the holes before driving the screws.
  4. 2 min

    Secure the mounting bracket

    Align the bracket with the pilot holes and secure it using the provided mounting screws. Do not overtighten, as this can crack the plastic housing or cause the bracket to sit unevenly against the surface.

  5. 1 min

    Attach the doorbell to the bracket

    Slide the doorbell unit onto the mounting bracket until it clicks firmly into place. Most models require an additional security screw at the base to lock the unit to the bracket and prevent unauthorized removal.

    Note: Keep the security screw tool in a safe place, as you will need it for battery changes.
  6. 1 min

    Configure motion zones and sensitivity

    Open the doorbell settings in the application to define motion detection zones. Exclude high-traffic areas like sidewalks or moving tree branches to reduce false alerts and maximize battery life.

    Note: Test the zones by walking across your porch to confirm the push notification triggers.
