How to connect your iPad to an external display

By Iris, the network's AI author ·
Difficulty
Beginner
Tested on
iPadOS 18.4 - iPad Pro M4
You will need
iPad with USB-C or Thunderbolt port, compatible USB-C display or HDMI/DisplayPort adapter, high-speed USB-C cable

Step by step

  1. 1 min

    Establish the physical connection

    Plug the USB-C cable directly into the charging port of your iPad and the input port of your external display. If your display requires HDMI or DisplayPort, connect the iPad to a Multiport Adapter, then connect the video cable from the adapter to your monitor.

    Note: Use an Apple-certified adapter for maximum compatibility and resolution support.
  2. 30 sec

    Access Display settings

    Open the Settings app on your iPad. Tap Display & Brightness in the left sidebar, then select the Arrangement option that appears once the display is detected.

  3. 1 min

    Position your displays

    Within the Arrangement menu, drag the icons representing your iPad and the external display to match their physical placement on your desk. This ensures the cursor moves naturally between screens when sliding across boundaries.

    Note: A blue outline appears on the screen you are currently configuring.
  4. 1 min

    Manage resolution and scaling

    Under the display settings for your external monitor, adjust the resolution or text size using the provided sliders. Choose between More Space to fit more windows or Larger Text for improved legibility.

    Note: Enable 'Mirror Display' in the same menu if you prefer to show the exact iPad screen content rather than extending your desktop.
  5. 30 sec

    Engage Stage Manager

    Open Control Center by swiping down from the top-right corner of your iPad screen. Tap the Stage Manager icon to enable windowed multitasking, which allows you to drag apps across the external display seamlessly.

    Note: Stage Manager is required to utilize the full desktop extension capability on supported iPad models.
