How to Install and Configure Your Ring Video Doorbell

Step by step

1. 2 min

   Charge the internal battery

   Remove the doorbell from its packaging and charge the battery fully using the included micro-USB or USB-C cable. Wait for the indicator light to glow solid green before proceeding to ensure the device performs firmware updates correctly during setup.

   Note: If you are hardwiring the device, a full initial charge is still required to stabilize the unit.
2. 5 min

   Add the device in the Ring app

   Download the Ring app from the App Store and sign in or create an account. Tap Set Up a Device, select Doorbells, and scan the QR code located on the back of the device or on the included Quick Start Guide.

   Note: Ensure your smartphone's Bluetooth is enabled to facilitate the initial handshake between the app and the doorbell.
3. 3 min

   Connect to Wi-Fi

   Follow the in-app prompts to join the temporary Ring Wi-Fi network generated by the doorbell. Once connected, select your local 2.4GHz network from the list and enter your password to finalize the cloud registration.

   Note: Ring devices perform best on 2.4GHz networks due to superior range through walls and doors.
4. 5 min

   Mark and drill installation holes

   Hold the mounting bracket against your door frame at chest height, roughly 48 inches from the ground. Use a pencil to mark the screw positions, then use a drill and the provided drill bit to create pilot holes for the mounting screws.

   Note: If installing on brick or concrete, use the included plastic wall anchors to ensure a secure fit.
5. 2 min

   Mount the doorbell

   Align the doorbell with the mounting bracket and drive the mounting screws into the pilot holes. Tighten the security screw on the bottom of the faceplate using the included star-shaped screwdriver to lock the unit in place.

   Note: Do not overtighten the screws as this can crack the plastic housing.
